Maximum Range
|
42 miles / 68km
|
|
Recharge Time
|
6 hours
|
|
Maximum Assisted Speed
|
15.5mph / 25kmh
|
|
Motor
|
Bafang rear hub motor, 36v 250w, 32nm torque, 25kmh max speed
|
|
Motor Type
|
Rear hub motor
|
|
Motor Torque
|
32nm
|
|
Battery
|
Integrated 540wh (36V 15.0ah), Samsung cells, Removable for charging on or off the bike
|
|
Battery Type
|
Integrated
|
|
Charger
|
42V 2A, 3 pin UK plug
|
|
Display
|
Centre mounted LCD display with remote, 5 modes, Walk assist, Lights on/off, Battery Indicator, Speed, Average speed, Max speed, Odometer, Trip, Trip Time,
|
|
Speed Sensor
|
Left hand crank mounted
|
|
Frame
|
6061 aluminium low step frame, Internal cable routing, Fully integrated removable battery, 700c wheels
|
|
Frame Size
|
Medium
|
|
Fork
|
700c suspension fork, Hydraulic lockout, 70mm travel
|
|
Headset
|
Sealed bearings
|
|
Handlebar
|
Aluminium, 680mm wide, 15° backsweep
|
|
Stem
|
Adjustable, Aluminium, 90mm reach, 31.8mm
|
|
Grips
|
Ergonomic comfort, Lock on, Black
|
|
Gear Shifters
|
Shimano Altus SL-M2010 Rapidfire Plus, 9 speed
|
|
Rear Derailleur
|
Shimano Alivio RD-M3100 Shadow, 9 speed
|
|
Chain
|
KMC Z9, 9 speed
|
|
Cassette/Freewheel
|
Shimano Altus CS-HG201, 11-36T, 9 speed
|
|
Chainset
|
Aluminium, 42T, 170mm
|
|
Number of Gears
|
9
|
|
Bottom Bracket
|
Sealed
|
|
Pedals
|
Alloy city style, Black
|
|
Brakes
|
Tektro M275 hydraulic disc, 180mm rotor (front), 160mm rotor (rear)
|
|
Brake Levers
|
Tektro M275 hydraulic disc
|
|
Front Hub
|
Alloy with quick release, 36 hole
|
|
Rear Hub
|
Bafang rear hub motor, 36v 250w, 32nm torque, 25kmh max speed
|
|
Rims
|
700c double wall alloy, 36 hole
|
|
Tyres
|
Kenda K197, 700x45c, Puncture protection and reflective side strip
|
|
Saddle
|
Selle Royal Freeway
|
|
Seat Post
|
Aluminium, 350mm, 30.4mm
|
|
Lights
|
Front - Star Union LED, 20 Lux, Fork mounted, Powered by bike battery / Rear - Star Union 3 LED with integrated reflector, Pannier rack mounted, Powered by bike battery
|
|
Mudguards
|
Full length, 56mm wide, Black
|
|
Kickstand
|
Chainstay mounted, Aluminium
|
|
Pannier Rack
|
Aluminium with rear light mounted
|
|
Maximum Range
|
42 miles / 68km
|
|
Recharge Time
|
6 hours
|
|
Maximum Assisted Speed
|
15.5mph / 25kmh
|
|
Motor
|
Bafang rear hub motor, 36v 250w, 32nm torque, 25kmh max speed
|
|
Motor Type
|
Rear hub motor
|
|
Motor Torque
|
32nm
|
|
Battery
|
Integrated 540wh (36V 15.0ah), Samsung cells, Removable for charging on or off the bike
|
|
Battery Type
|
Integrated
|
|
Charger
|
42V 2A, 3 pin UK plug
|
|
Display
|
Centre mounted LCD display with remote, 5 modes, Walk assist, Lights on/off, Battery Indicator, Speed, Average speed, Max speed, Odometer, Trip, Trip Time,
|
|
Speed Sensor
|
Left hand crank mounted
|
|
Frame
|
6061 aluminium low step frame, Internal cable routing, Fully integrated removable battery, 700c wheels
|
|
Frame Size
|
Small
|
|
Fork
|
700c suspension fork, Hydraulic lockout, 70mm travel
|
|
Headset
|
Sealed bearings
|
|
Handlebar
|
Aluminium, 680mm wide, 15° backsweep
|
|
Stem
|
Adjustable, Aluminium, 90mm reach, 31.8mm
|
|
Grips
|
Ergonomic comfort, Lock on, Black
|
|
Gear Shifters
|
Shimano Altus SL-M2010 Rapidfire Plus, 9 speed
|
|
Rear Derailleur
|
Shimano Alivio RD-M3100 Shadow, 9 speed
|
|
Chain
|
KMC Z9, 9 speed
|
|
Cassette/Freewheel
|
Shimano Altus CS-HG201, 11-36T, 9 speed
|
|
Chainset
|
Aluminium, 42T, 170mm
|
|
Number of Gears
|
9
|
|
Bottom Bracket
|
Sealed
|
|
Pedals
|
Alloy city style, Black
|
|
Brakes
|
Tektro M275 hydraulic disc, 180mm rotor (front), 160mm rotor (rear)
|
|
Brake Levers
|
Tektro M275 hydraulic disc
|
|
Front Hub
|
Alloy with quick release, 36 hole
|
|
Rear Hub
|
Bafang rear hub motor, 36v 250w, 32nm torque, 25kmh max speed
|
|
Rims
|
700c double wall alloy, 36 hole
|
|
Tyres
|
Kenda K197, 700x45c, Puncture protection and reflective side strip
|
|
Saddle
|
Selle Royal Freeway
|
|
Seat Post
|
Aluminium, 350mm, 30.4mm
|
|
Lights
|
Front - Star Union LED, 20 Lux, Fork mounted, Powered by bike battery / Rear - Star Union 3 LED with integrated reflector, Pannier rack mounted, Powered by bike battery
|
|
Mudguards
|
Full length, 56mm wide, Black
|
|
Kickstand
|
Chainstay mounted, Aluminium
|
|
Pannier Rack
|
Aluminium with rear light mounted
|
